One of the great things about triking is how nice it is to have everything right at hand as you roll along. With a SeatSide mount, you can have all sorts of things close at hand. The Catrike SeatSide Mount lets you carry bags, water bottles, cameras, all sorts of things, right by your side. Snacks, phones, lip balm, you name it, now you can keep it all within reach while riding. This version of the SeatSide Mount for Catrikes attaches to the seat frame. We make other versions that attach to the main frame tube. We recommend this version of the mount for people that simply want a good sturdy place to mount things beside the seat. If you want maximum versatility in where things are located or need quick on/off removability, check out the main frame mounted version.
FAQ
1. How does it work?
Specially machined clamps attach to the seat frame. For Catrikes that don't fold, they go on the straight part under the seat between the main tube and where it bends up. On Catrikes that fold, a different set of clamps go on back of the seat near where the seat angle adjusts. A support tube comes out sideways and over to where the accessory mounting tube needs to be. The end of the support tube has a T clamp that holds the horizontal accessory mounting tube beside the seat. The accessory mounting tube is long enough to hold whatever you'd like.
2. I've seen ICE trikes with something similar. Is this like that?
The stock ICE side mount is vaguely similar, but it has a smaller accessory mounting area than the ones we make and is only adjustable left/right. On our mounts, everything is clamped, not welded, so you can adjust things up/down, left/right, and forward/back. The space provided to mount accessories is about 3 times as long. If you want to really customize it, you can shorten any of the tubes, or even substitute another of a different size. We make a version for ICE trikes, too, of course, in which case the mounts would be very similar. On the ICE trikes, the tube that you attach to is behind the seat, rather than under the seat, so how you get from there out to the side of the seat is a little different.
3. Which side does it go on?
Either, or both, it's up to you. If you have a folding Catrike, we make a double mount that does both sides with one mount and one set of seatback clamps. If you have a non folding Catrike, you have to use two separate single sided mounts to get one on each side.
4. Will this work with any bag?
Yes, the tube where the accessories mount is 7/8in (22.2mm) diameter, so pretty much anything designed to mount to a bike or to handlebars can attach there. If you ever need shims for your bag, let us know.
5. What can you put on it?
Anything that you can attach to a standard 7/8in (22.2mm, standard handlebar size) tube. Handlebar bags, water bottles, phones, things like that. The supplied accessory mounting tube is 11 inches (28cm) long, so you have lots of room. We have longer tubes if you really want to go crazy.
6. How much weight can it hold?
A lot, but obviously it has it's limits. We're saying 10lbs (4.5Kg) to be on the safe side. We do recommend that if you want to carry living things (like pets) that you do so carefully.
INSTALLATION INSTRUCTIONS
Installation is straightforward.
- If you have a non folding Catrike, you first attach the (long) clamps to the seat frame under the seat. If you have a folding Catrike, you attach the (short) clamps behind the seat.
- Next, you assemble the accessory mounting tube to the T clamp on the support tube.
- You then slide the support arm into the clamps on the seat and adjust the system to the left/right, up/down, and forward/back position you'd like.
You're ready to install your accessories!
ADDITIONAL INFO
- We include a user installed catchpost in case you want to use a handlebar bag that is designed to index to the handlebar stem on an upright bike. Some handlebar bags have a cable or an arm that is designed to catch on a handlebar stem to keep the bag from rotating down. The catchpost provides a place for that to connect.
- We make a lot of tubes and clamps that are compatible with this system if you need to do customizations. Check out the Seatside Mount Hardware and Cockpit Mount Hardware pages for more information.
- Clamps are CNC machined aluminum, anodized black, with all stainless fasteners. Tubes are black powder coated aluminum with removable black end caps.
- Custom configured to fit all Catrikes (and possibly Musashis, haven't tested that yet).
Not Quite Right
The two screws in the middle of the clamp were too short to reattach. Fortunately, I had other screws, which I were able to use to tighten the clamp to complete the installation of this kit!
United StatesReally well thought-out design, easy to install
The instructions were clear and thorough, the installation was very straightforward. I got a two-sided mount for my Catrike Dumont, it fits very well, there are a lot of adjustments to make sure the mount and the bag don't get in the way of anything. Very solid once all bolts are tight.
United StatesSimple as pie.
Adding the SeatSide to my Catrike Dumont was easy and straight-forward. Thank you TerraCycle for another great product.
United StatesAs always T-cycle delivers quality goods
Switched to a tadpole (Catrike) last year. T-cycle is the go to outfitter for all my customization products.
United StatesThanks!
I love the seat side mounts. They hold the bags right where I need access to them. The owner and staff are excellent people to work with and I would recommend wholeheartedly.
